Zhongtuo Roll Forming Machinery Co., ltd

Downcomer gutter pipe production line
Downcomer gutter pipe production line
Downcomer gutter pipe production line
Downcomer gutter pipe production line
Downcomer gutter pipe production line

Downcomer gutter pipe production line

Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Delivery Time: 30 Days

Contact Now

Basic Info

    Model No.: ZT-002

    Material: Color Steel Plate

    Type: Ridge Tiles

    Shape: Plain

    Size: 300*400mm

    Color: Blue, As You Want

    Customized: Customized

    Weight: 7t

    Place Of Origin: China

    Roller Diameter: 80mm

    Roller: 26

    Machine Size: 7*1.5*1.2m

    Certificate: CE&ISO

    Total Power: 7kw

    Raw Material Size: Color Steel Sheet

Additional Info

    Packaging: naked

    Productivity: 20sets/month

    Brand: Zhongtuo

    Transportation: Ocean,Land

    Place of Origin: China

    Supply Ability: 20sets/month

    Certificate: CE&ISO

Product Description

Downcomer gutter pipe production line

The function of downcomer gutter pipe production line is to collect rainwater from the roof and concentrate it into the rainwater pipe laid below the ground. Most buildings have the rain gutter pipe. Take the following square Galvanized steel water tube /pipe/gutter rolling machine for example to show how the gutter pipe machine is composed:

rain gutter pipe line drawing profile

half round gutter pipe machine

A , Technical parameter of downcomer making machine:
1. Machine stand: adopts steel structure welded frame
2. Locating of movable station: fixed with square key and screw
3. Install bearing type: taper bearing install in pairs
4. Guiding with feeding stand type: side trolley type
5. Form of forming machine: singlestation with chain transmission
6. Specification of single station: WHPF30
7. leader: ¢30㎜
8. diameter of bearing assembly position: ¢50㎜
9.diameter of shaft: ¢60㎜
10. Chain: 16A single row
11.motor power of forming machine:5.5kw
12.line speed:10m/min
13. Roller station: 17 stations and a series of vertical roller
14.material of roller:high-grade 45#steel
15. Surface of roller coated with chrome of thickness 0.05mm
16.motor power of hydraulic station:3kw
17.hydraulic oil pump:gear pump CB-E314
18.cutting type:adopts hydraulic cutting type after forming mould
19.material of cutting blade:Cr12
20.heat treatment of cutting blade:HRC58°-60°
21.material :0.5-0.7 mm Color Steel Coil
22.length tolerance:±2mm
23. Transducer: Holip (Danfoss)
24.computer adopts PLC,Omron
25. computer operating board adopts Xinjie OP320A
B, Elbow machine
1.Control method:Electrical control
2.Main motor power:2.2KW
3.Max elbow angle:90
4.Function:curving the pipe and locking mouth

Gutter Pipe Production Line

Rain Gutter Pipe Line

Downcomer Making Machine

If you need the pipe Bending Machine, we also can provide:

pipe bending machine



Looking for ideal Rain Gutter Pipe Line Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Gutter Pipe Production Line are quality guaranteed. We are China Origin Factory of Downcomer Making Machine. If you have any question, please feel free to contact us.
