Zhongtuo Roll Forming Machinery Co., ltd

C Z Purlin Roll Forming Machine
C Z Purlin Roll Forming Machine
C Z Purlin Roll Forming Machine
C Z Purlin Roll Forming Machine
C Z Purlin Roll Forming Machine

C Z Purlin Roll Forming Machine

Unit Price: USD 20000 - 5000 / Set/Sets
Payment Type: L/C,T/T,D/P,D/A
Incoterm: FOB
Min. Order: 1 Set/Sets
Delivery Time: 30 Days

Contact Now

Basic Info

    Model No.: ZT-006-97

Additional Info

    Packaging: as customer's need

    Productivity: 15-50m/min

    Brand: zhongtuo

    Transportation: Ocean,Land,Air

    Place of Origin: China(mainland)

    Supply Ability: 30 sets/month

    Certificate: CE,ISO,SGS,IAF,CNAS.

Product Description

C Z Purlin Roll Forming Machine

Support you money !! Support you service !! Support you technology !!

PLC control system !! Hydraulic cutting system !! Mult-language conversion system !!


C Z Purlin Roll Forming Machine Decoiler System:

Usage: Passive uncoil pulled by roll forming system, support the steel coil and uncoil it in a turntable way.

No :

Decoiler System Main Parameter :

1

Loading capacity

1-5T

2

Uncoiling width

300-1000mm

3

Inner diameter

450-550mm

keel roll forming machine 2

C Z Purlin Roll Forming Machine Roll Forming System:

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, gear transmission, roller surfaces polishing, hard plating , heat treatment and galvanizational treatment.

No :

Roll Forming System Main Parameter :

1

Length of the main part

about 3000*1000*400-8800*1800*1500

2

Weight of main part

3-6tons

3

Voltage

380V/50HZ3Phase (as customer`s request)

4

Roller fixer

guide column

5

Frame

steel plate welded/ Memorial arch frame type

6

Frame thickness

15-30mm

7

Drive mode

gear

8

Material of rollers

GCr15MoV

9

Material of shafts

45# steel with tempering

10

Diameter of shafts

φ40-60mm

11

Number of rollers

10-15 rollers

12

Main power

3-11kw

2 (2)

C Z Purlin Roll Forming Machine Automatic Cutting System:

Feature: Automatic cutting controlled by PLC. Ensure stability, precision and cutting speed. It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.

No :

Cutting System Main Parameter :

1

Material of blades

Gcr12MoV quenched

2

Power supply

hydraulic power

3

Frame

Pillar style with rack & pinion system

4

Stroke switch

non-contact photoelectric switch

5

Hydraulic motor Power

3-6kw

6

Hydraulic oil:

46#

C Z Purlin Roll Forming Machine Electric Control System:

1. Adopted PLC , transducer, touch panel from Delta Taiwan to ensure high speed with stability, precision and lifetime.

2. Equipped with movable switch , air break, radiator, transformer & electric leakage protector for operation convenience and safety.

C Z Purlin Roll Forming Machine Company Information:

Cangzhou Zhongtuo International Trade Co., Ltd is a professional manufacturer located in northwest of CangZhou, as a long history of cold roll formingmachine production base. All products comply with international quality standards and are greatly appreciated in variety of different markets throughout the world, such as Asia, Africa, Europe,South America, and Australia and so on.


Looking for ideal Beam Straightening Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Purlin Roll Forming Machine are quality guaranteed. We are China Origin Factory of C Z Purlin Roll Forming Machine. If you have any question, please feel free to contact us.

Product Categories : C/Z/U Purline Roll Forming Machine > U Bracket Solar Power Stent Manufacturing Series
